Процессорные модули
Характеристики
- Встроенные каналы дискретного ввода/вывода: 16DI, 8DO;
- Высокоскоростные каналы ввода/вывода: счетчик импульсов, 100 кГц;
- Поддержка протоколов - Modbus RTU/TCP (Master, Slave), Free Port Agreement
- Возможность расширения интерфейсов за счет BD плат: GRPS, ZIGBEE, LoRa;
- Питание: 24VDC, 220VAC;
- Диапазон рабочих температур: 10°C ~ +55°C;
Модели
Снято с производства
CPU2002-2404
16*DI, 8*DO-Relay, AC220V, 2 points high-speed counting, 2*Ethernet, 2*RS485, Program memory: 1.5M
Под заказ
CPU2002-2403
16*DI, 8*DO-Transistor (sink NPN), AC220V, 2 points high-speed output, 2 points high-speed counting, 2*Ethernet, 2*RS485, Program memory: 1.5M
Под заказ
CPU2002-2402
16*DI, 8*DO-Relay, DC24V, 2 points high-speed counting, 2*Ethernet, 2*RS485, Program memory: 1.5M
Под заказ
CPU2002-2401
16*DI, 8*DO-Transistor (sink NPN), DC24V, 2 points high-speed output, 2 points high-speed counting, 2*Ethernet, 2*RS485, Program memory: 1.5M
Под заказ
CPU2001-2421
16*DI, 8*DO-Transistor (sink NPN), DC24V, 4 points high-speed output, 2 points high-speed counting, supporting arbitrary dual axis line and arc Interpolation, 2*Ethernet, 2*RS485
Под заказ
CPU2001-2411
16*DI, 8*DO-Transistor (sink NPN), DC24V, 4 points high-speed output, 2 points high-speed counting, 2*Ethernet, 2*RS485
Под заказ
CPU2001-2404
16*DI, 8*DO-Relay, AC220V, 2 points high-speed counting, 2*Ethernet, 2*RS485
Под заказ
CPU2001-2403
16*DI, 8*DO-Transistor (sink NPN), AC220V, 2 points high-speed output, 2 points high-speed counting, 2*Ethernet, 2*RS485
Под заказ
CPU2001-2402
16*DI, 8*DO-Relay, DC24V, 2 points high-speed counting, 2*Ethernet, 2*RS485
Под заказ
CPU2001-2401
16*DI, 8*DO-Transistor (sink NPN), DC24V, 2 points high-speed output, 2 points high-speed counting, 2*Ethernet, 2*RS485
Под заказ
